110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN

China 110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier
110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier 110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier 110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier 110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier 110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN supplier

Large Image :  110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN

Product Details:

Place of Origin: China
Brand Name: Boyu
Certification: ISO9001
Model Number: TY40

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Container
Delivery Time: 25-35 days
Payment Terms: TT/LC
Supply Ability: 100sets/month.
Price terms.: FOB(Shanghai) or CIF (assigned port).
Contact Now
Detailed Product Description
After Sales Service: Available OEM: Avaiable
Diesel: Cummins 77kw 103hp Max Reel Size: 1200mm
Main Pump And Motor: German Rexroth Tail Bracket Hoisting Motor: American Eton

Max Intermittent Pull 4Tons 40kN 110kv Transmission Line Stringing Equipment Main Pump German Rexroth TY40

Quick details:

  • 110kv Tansmission Line Stringing Equipment
  • Max rope diameter: 16mm
  • Hydraulic Puller
  • Max pull: 40kN 4Tons
  • Diesel: Cummins 77kw 103hp
  • Max reel size: 1200mm
  • Main pump and motor: German Rexroth
  • Tail bracket hoisting motor: American Eton
  •  Boyu Brand

Performance


1.Max intermittent pull: 40kN
2.Max continuous pull: 30kN
3.Speed at max pull: 2.5km/h
4.Max speed: 5km/h
5.Pull at max speed: 20kN


Engine

  • Diesel 77kw 103hp
  • Cooling system: water
  • Electrical system: 24V


Description


Together with tension machine, this model allows for the tension stringing of 220kV lines in mountainous and hilly areas and can be used for the traction stringing of OPGW or ADSS cable in various terrains.

Characteristics

  • Bull-wheel diameter: 400mm
  • Groove number: 7
  • Max rope diameter : 16mm
  • Max diameter of rope reel: 1200mm
  • Total weight: 3000kg
  • Overall dimension (length*width*height): 3600×2100×2200mm

Main configuration

  • Engine: Cummins
  • Main pump: German Rexroth
  • Main motor speed reducer: German Rexroth
  • Tail bracket hoisting motor: American Eton
  • Hydraulic meter: German WIKA
  • Operating handle: German Rexroth

Configuration

  1. Hydraulic dynamometer with set-point and automatic control of maximum pull
  2. Hydraulic oil cooling system
  3. Control instruments for hydraulic system and diesel engine
  4. On board reel winder with automatic level wind, suitable for standard reel mod. 1100 and 1200
  5. Manual front stabilizer
  6. Grounding connection point

Hydraulic Transmission
Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with a pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.

Additional Devices

  1. Lighting system for the trailer
  2. Hydraulic rope clamp for reel change(extra charge)
  3. Swivel guide rope roller
  4. Trailer for towing at max speed of 30 km/h
  5. Extra shaft
  6. Digital speed and meter counter


110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN


Customers
110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN


More pictures
110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN


Company Introduction
Established in 1997, Yixing Boyu Electric Power Machinery Co., Ltd. is a manufacturer specialized in the research, development and production of Electric Power Machinery.
We are located in beautiful and rich city: Yixing city. We are a High-tech enterprise in Jiangsu Province, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
  1. Main configurations of our machine are from Germany and USA
  Engine: American Cummins
  Main pump: German Rexroth
  Main motor& speed reducer: German Rexroth
  Tail bracket hoisting motor: American Eton
  Hydraulic meter: German WIKA
  2. Our company was founded in 1997, having 15 years rich experience in this field. Our product sells in distant markets: Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Germany etc. Our product is also very popular in china.
  3. We have one year quality guarantee, if internal components go wrong within one year, we will change another for free.
  4. We can supply the specific components to the buyers with cost price after warranty period.


Work site
110kv Transmission Line Stringing Equipment Main Pump German Rexroth Max Intermittent Pull 4 Tons 40kN


Max Intermittent Pull 4Tons 40kN 110kv Transmission Line Stringing Equipment Main Pump German Rexroth TY40



TY40 Hydraulic Puller

Together with tension machine, this model allows for the tension stringing of 220kV lines in mountainous and hilly areas and can be used for the traction stringing of OPGW or ADSS cable in various terrains.

Characteristics

Bull-wheel diameter: 400mm

Groove number: 7

Max rope diameter : 16mm

Max diameter of rope reel: 1200mm

Total weight: 3000kg

Overall dimension (length*width*height): 3600×2600×2200mm

Performance

Max intermittent pull: 40kN

Max continuous pull: 30kN

Speed at max pull: 2.5km/h

Max speed: 5km/h

Pull at max speed: 20kN

Engine

Diesel 77kw(103hp)

Cooling system water

Electrical system 24V

Main configuration

Engine: Cummins

hydraulic pump: German Rexroth

Main motor: German Rexroth

speed reducer: German Rexroth

Tail bracket hoisting motor: American Eton

Hydraulic meter: German WIKA

Operating handle: German Rexroth

Hydraulic Transmission

Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with a pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.

Configuration

Hydraulic dynamometer with set-point and automatic control of maximum pull

Hydraulic oil cooling system

Control instruments for hydraulic system and diesel engine

On board reel winder with automatic level wind, suitable for standard reel mod. 1100 and 1200

Mechanical front stabilizer

Grounding connection point

Additional Devices

Lighting system for the trailer

Hydraulic rope clamp for reel change

Swivel guide rope roller

Trailer for towing at max speed of 30 km/h

Extra shaft

Digital speed and meter counter (extra charge)
