TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine

China TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine supplier
TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine supplier TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine supplier

Large Image :  TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine

Product Details:

Place of Origin: China
Brand Name: Boyu
Certification: ISO9001
Model Number: TY90

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Container
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Contact Now
Detailed Product Description
Bull-wheel Diameter: 540mm Groove Number: 8
Max Rope Diameter: 21mm Max Diameter Of Rope Reel: 1400mm
Total Weight: 4350kg Overall Dimension (length*width*height): 4500×2100×2450mm
Engine: Cummins Hydraulic Pump: German Rexroth

TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine



TY90 Hydraulic Puller

This machine allows for the tension stringing of twin-bundle conductor of 500mm2 and below in mountainous and hilly areas, of twin-bundle conductor of 630mm2 and below in flat lands, and of single conductor 720mm2 in various terrains; besides, it can be used for traction stringing of OPGW or ADSS optical cable and 220kV haulage rope in various terrains.



Characteristics

  • Bull-wheel diameter: 540mm
  • Groove number: 8
  • Max rope diameter : 21mm
  • Max diameter of rope reel: 1400mm
  • Total weight: 4350kg
  • Overall dimension (length*width*height): 4500×2100×2450mm

Performance

  • Max pull: 100kN
  • Max continuous pull: 90kN
  • Speed at max pull: 2.5km/h
  • Max speed: 5km/h
  • Pull at max speed: 40kN

Main configuration

  • Engine: Cummins
  • hydraulic pump: German Rexroth
  • Main motor: German Rexroth
  • speed reducer: German Rexroth
  • Tail bracket hoisting motor: American Eton
  • Hydraulic meter: German
  • Operating handle: German Rexroth

Engine

  • Diesel 118kw(158hp) Euro II, 4-stroke cycle, turbo-charged
  • Cooling system liquid
  • Electrical system 24V

Hydraulic Transmission

  • Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with a pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.

Configuration

  • Hydraulic dynamometer with set-point and automatic control of maximum pull
  • Hydraulic oil cooling system
  • Control instruments for hydraulic system and diesel engine
  • On board reel winder with automatic level wind, suitable for standard reel mod. 1100 and 1400
  • Hydraulic front stabilizer
  • Grounding connection point

Additional Devices

  • Lighting system for the trailer
  • Hydraulic rope clamp for reel change
  • Swivel guide rope roller
  • Trailer for towing at max speed of 30 km/h
  • Extra shaft
  • Digital speed and meter counter (extra charge)

Additional Devices

  • The chassis provided with Brake, back lights and mudguard, with a single point lift to allow lifting with a crane.
  • Cable and radio remote control fully replacing all controls at machine panel.
  • Remote diagnosis via GSM network with GPS modem, Synchronization system
  • Hydraulic system for drum stand control with flat face quick action couplings
  • Auxiliary Hydraulic system (700/1000 bar) for power pressing tool
  • Lockable toolbox, Holding fixture for hose kit, Grounding plate, Acoustic insulation
  • Biodegradable hydraulic oil, Allowable tension indictor, Overload tension alarm, First Aid Kit
  • Manufacturer's workshop maintenance manual, in English
  • Manufacturer's recommended tools.
  • Manufacturer's routine spares for five years' duty (filters, bulbs, etc.).


TY90 Max Pull 100kN Cummins Engine Hydraulic Cable Puller For Overhead Stringing Machine
