10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency

China 10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency supplier
10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency supplier 10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency supplier

Large Image :  10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency

Product Details:

Place of Origin: China
Brand Name: Boyu
Certification: ISO 9001
Model Number: HSZ-10A

Payment & Shipping Terms:

Minimum Order Quantity: 2
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 15~30 days
Payment Terms: L/C, T/T
Supply Ability: 10000 Sets/Month
Contact Now
Detailed Product Description
OEM Serive: YES Lifting Chain Number: 4
Standard Lifting Height: 3m Net Weight: 83kg
Lifting Chain Diameter: 10mm Package Dimensions: 50x41x21cm
Type: Chain Hoist Test Load: 125KN





10T Hand Chain Block Transmission Line Stringing Tools HSZ-10A Durable Heavy Duty Specification of Lifting Chain Hoist



Quick Detail

  • Manual pull lift chain hoist
  • Smooth rotation, high efficiency and small manual tension.
  • The shell material is high-quality alloy steel, strong and wearable, high safety performance.
  • It adopts low-alloy structural steel plat, which is safe, reliable and durable. Small size, light weight and easy to carry.
Model HSZ-0.5A HSZ-1A HSZ-1.5A HSZ-2A HSZ-3A HSZ-5A HSZ-10A HSZ-20A HSZ-30A HSZ-50A
rated load lifting capacity ton 0.5 1 1.5 2 3 5 10 20 30 50
Standard lifting height m 2.5 2.5 2.5 3 3 3 3 3 3 3
Test load KN 6.3 12.5 18.7 25 37.5 63 125 250 375 625
Hand pull when fully loaded N(KG)

200

(20.5)

304

(31)

343

(35)

410

(41.8)

343

(35)

414

(42.2)

423

(43.2)

435x2

(44.3x2)

435x2

(244.3x2)

435x2

(244.3x2)

Lifting chain number 1 1 1 1 2 2 4 8 12 22
Lifting chain diameter mm 6 6 8 8 8 10 10 10 10 10

Main dimensions

mm

A 113 126 141 141 141 163 163 191 312 496
B 125 147 183 183 183 215 404.5 595 691 958
C 255 306 368 368 486 616 750 1000 1380 2578
D 36 40 45 50 58 64 85 110 110 170
K 30 34 38 41 48 52 64 85 81 125
Net weight kg 8.5 11 18 18.5 27 42 83 193 220 1092
Package dimensions cm

26*19

*14

26*

21*15

33*

26*16

33*2

6*16

33*

27*16

43*

34*19

50*

41*21

64*

38*64

72*50*68 110*100*130
Increase in weight per 1 meter increase in height kg 1.7 1.7 2.3 2.3 3.7 5.3 9.7 19.4 28.2 50.2




Description

  • Using 800Mpa high-strength lifting chain and forged hook design to ensure slow lifting to prevent overload.It meets European CE safety standards. High safety factor and long service life.
  • Double pawl and stamping guide chain plate (double guide wheel structure selection) are more safe and reliable.
  • This product has been widely used in nuclear power, thermal power, power transmission and transformation.
  • The overall bearing is adopted, which greatly improves the performance, service life and easy maintenance of the product.
  • The structure is compact and reasonable, the whole machine runs smoothly, and the appearance is beautiful and novel.
  • The unique overload device (the use of one-way clutch) patent technology for selection.
  • Designed and manufactured according to the standard of En13157.
  • The main components and the performance of the whole machine are strictly checked and tested. The reliability of the product is greatly improved and the use is safe.

10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency

Workshop

10T Transmission Line Stringing Tools Heavy Duty Chain Pulley Block High Efficiency
